Cultivator for continuous cultivation КПСО-4 (Т)
Learn moreMore about "Cultivator for continuous cultivation КПСО-4 (Т)"
| Parameter | Value |
|---|---|
| Тип | Причіпний |
| Потужність трактору, не менше, к.с. | 100 |
| Глибина обробітку, см | 5-12 |
| Продуктивність, га/год | 3,5-4,0 |
| Робоча швидкість, не більше, км/год | 12 |
KPSO-4 (T) with reinforced tandem support wheels
A universal, wide-working cultivator designed for resource-saving pre-sowing and in-season (steam) soil cultivation, weed cutting and raking, as well as leveling and compacting the soil surface for sowing.
It is applicable on all types of soil due to its versatility, provided by the numerous adjustments of the cultivator and its additional equipment.
|
No. z/p |
Parameter Name |
Parameters |
||||
|
KPSO-4 |
KPSO-5 |
KPSO-6 |
KPSO-8 |
KPSO-10 |
||
|
1 |
Cultivator productivity per hour of main operation, ha/h |
3.5–4.0 |
4.5–5.0 |
5.0–5.5 |
7.5–8.0 |
8.5–9.0 |
|
2 |
Minimum tractor drawbar power, hp |
100 |
120 |
150 |
200 |
240 |
|
3 |
Working speed, not more than, km/h |
12 |
||||
|
4 |
Weight, kg |
1625 |
2050 |
2800 |
3900 |
4200 |
|
5 |
Working width, m |
4.2 |
5.0 |
6.0 |
8.0 |
10.0 |
|
6 |
Cutting sweep width, mm |
260 |
||||
|
7 |
Tillage depth, up to, cm |
5–12 |
||||
|
8 |
Tillage depth for weed removal, cm |
7 |
||||
|
9 |
Number of cutting sweeps, pcs |
20 |
26 |
31 |
41 |
49 |
|
10 |
Number of packer drums, pcs |
2 |
2 |
4 |
4 |
6 |
|
11 |
Overall dimensions, m |
|
||||
|
|
– Length |
5.4 |
7.7 |
7.6 |
7.6 |
|
|
|
– Working/transport width |
4.2 |
5.2 |
6.2/4.2 |
8.6/4.9 |
9.9/4.9 |
|
|
– Working/transport height |
1.0/1.3 |
1.0/1.3 |
1.4/2.6 |
1.4/3.2 |
1.4/3.8 |
|
13 |
Maximum transport speed, km |
20 |
||||
|
14 |
Road clearance, mm |
300 |
||||
|
|
|
|||||
