Deep ripper ГРД-4 (2600)

Learn more

More about "Deep ripper ГРД-4 (2600)"

No reviews

180 000 грн

0 грн

State compensation: 1 грн

*You can find out the exact price from the manager

Technical specifications

Parameter	Value
Тип	Навісний
Транспортна швидкість, не більше, км/год	15
Вага, кг	1080
Ширина обробітку, м	2,6
Кількість стійок, шт.	4
Відстань між стійками, см.	75
Тягова потужність трактору, не менше, к.с	120
Максимальна глибина обробітку, см	45
Робоча швидкість, км/год	7-10
Довжина, м	2,3
Ширина, м	3,0
Висота, м	1,34

Description

The purpose of the subsoiler is to destroy the plow pan, preserve moisture, help regulate the air-water balance, and increase fertility.

The HRD subsoiler helps to:

create conditions for the accumulation of moisture from the air and its even distribution;
increase porosity and improve the soil’s capillary system;
activate biological processes that promote active root system development of crops and increase yields by 12-18%;
remove excess rain and meltwater;
reduce soil resistance when tractors operate with other equipment. This occurs by decreasing soil density, leading to fuel savings, reduced consumption of lubricants, and lower service loads;

Technical characteristics of subsoilers

Name of parameter	Value
Name of parameter	HRD-4
Productivity per 1 hour of main operation, ha/h	2.3
Number of working shanks, pcs.	4
Distance between shanks, cm	75
Tractor drawbar power, min, hp	120
Maximum working depth, cm	45
Working speed, not more than, km/h	7-10
Transport speed, km/h	up to 15
Weight, kg	990
Working width, m	2.3 (2.6)
Overall dimensions, m
- length	2.3
- width	2.86
- height	1.34
Road clearance, min, mm	350
Warranty period of operation, min, months	12
Warranty service life, ha	up to 500
Service life, min, years	8
