More about "Disc harrow ЛДД-2500 Centaur"
| Parameter | Value |
|---|---|
| Тип | Причіпний |
| Потужність трактору, не менше, к.с. | 80 |
| Продуктивність за 1 годину основного часу, га/год | 2,8 |
| Робоча швидкість до, км/год | 10-18 |
| Робоча ширина захвата, м | 2,5 м |
The LDD-2500 disc cultivator can be used with an MTZ-80 tractor in a trailed version with a transport device, or with more powerful tractors in a mounted version.
LDD-2500 DISC CULTIVATOR
Technical characteristics:
|
|
LDD-250P (Trailed) |
LDD-250N (Mounted) |
|
Tractor power, min (hp) |
80 |
80 |
|
Productivity per 1 hour of main operating time (ha/h) |
2.8 |
2.8 |
|
Working speed up to (km/h) |
10-18 |
|
|
Working width (m) |
2.5 |
2.5 |
|
Working depth (cm) |
3-14 |
|
|
Weight +/-3% (kg) |
1560 |
1120 |
|
Overall dimensions in working position (m) |
|
|
|
- length |
5.35 |
2.46 |
|
- width |
2.9 |
2.9 |
|
- height |
1.65 |
1.35 |
|
Overall dimensions in transport position (m) |
|
|
|
- length |
5.15 |
2.46 |
|
- width |
2.9 |
2.9 |
|
- height |
1.7 |
1.35 |
|
Transport speed, not more than (km/h) |
20 |
|
|
Number of working tools (pcs.) |
|
|
|
discs |
20 |
20 |
|
packer rollers |
1 |
1 |
|
Diameter of working tools (discs), cm |
51/56 |
|
|
Distance between working tools, cm |
25 |
|
|
Disc angle of attack, degrees |
20 |
|
|
Distance between rows of working tools, cm |
90 |
|
