More about "Disk peeler ЛДД-5000 Centaur"
| Parameter | Value |
|---|---|
| Тип | Причіпний |
| Потужність трактору, не менше, к.с. | 180 |
| Продуктивність за 1 годину основного часу, га/год | 5,6 |
| Робоча швидкість до, км/год | 10-18 |
| Робоча ширина захвата, м | 5,0 м |
The LDD-5000 cultivator is used for stubble cutting; primary shallow soil tillage; soil preparation for cereal, industrial, and fodder crops; it ensures the shredding and incorporation of crop residues from previous crops and uprooted vegetation; and is used to improve meadows and pastures.
Technical characteristics:
| Tractor power, not less than, hp | 180 |
| Productivity per 1 hour of main working time, ha/h | 5.6 |
| Working speed up to, km/h | 10-18 |
| Working width, m | 5.0 |
| Working depth, cm | 3-14 |
| Weight +/-3%, kg | 3280 |
| Overall dimensions in working position, m |
|
| - length | 6.13 |
| - width | 5.39 |
| - height | 1.5 |
| Overall dimensions in transport position, m |
|
| - length | 5.93 |
| - width | 2.65 |
| - height | 3.3 |
| Transport speed, not more than, km/h | 20 |
| Number of working tools, pcs. |
|
| discs | 40 |
| packer rollers | 2 |
| Working elements (discs) diameter, cm | 51/56 |
| Distance between working elements, cm | 25 |
| Disc angle of attack, degrees | 20 |
| Distance between rows of working elements, cm | 90 |
